VEVOR Dividing Head BS-1 Dividing Head Set 6\" 3-jaw Chuck Semi Universal Milling Set with 6\" Chuck+Tailstock+Dividing Plates,Silver

Name: VEVOR Dividing Head BS-1 Dividing Head Set 6\" 3-jaw Chuck Semi Universal Milling Set with 6\" Chuck+Tailstock+Dividing Plates,Silver
Brand: VEVOR
SKU: 1008680544
Price: 415.99 USD
Availability: InStock

undefined out of 5 stars with 0 reviews

New at

$415.99

In Stock

Sold & shipped by Vevor Store Inc

Eligible for registries and wish lists

About this item

Details

Highlights

Adjustable Headstock with 6″ Chuck
Rigid HT200 Body, 1:40 Ratio
Laser Scales for Precise Indexing
Complete Set with MT3 Tailstock

Description

Feature:

Adjustable Angle: The semi-universal dividing head features a 6" 3-jaw chuck, Spindle Speed: 2500 RPM. The headstock is adjustable from the horizontal position to 90 degrees upward. Swing: 6-1/2" / 168 mm, Center Height: 5" / 128 mm. Free 3 more jaws for 6" chuck.
Solid Construction: This indexing head is made of HT 200 to be a long life. A rigid frame provides high accuracy with little backlash for a smooth rotation. The reduction ratio is 1:40.
Precise & Accurate: Dividing head milling machine with laser engraving scales. The 24 quick-dividing holes can complete 2, 3, 4, 6, 8, 12, 24 division indexing. One circle for 360 degrees, one scale stands for 1 degree.
MT3 Tailstock Adjustable: Huge live center for heavy-duty workpieces. Ball-bearing precision; turns smoothly. The model of the tailstock is MT3. One extra dead center is included.
Rich Dividing Head Set: 3 dividing head index plates are attached along with the dividing head for indirect dividing in any division indexing 2-50, 51-380 except prime numbers and specific other numbers.

Package Content:

1 x 6" Dividing Head
2 x Dividing Plates
3 x 6" Chuck Jaws
1 x Dead Center
1 x Tailstock
1 x Set of Related Accessories

Specifications

Dimensions (Overall): 8.6 inches (H) x 4.4 inches (W) x 7.9 inches (D)

Weight: 77 pounds

Product Name: Dividing Head

TCIN: 1008680544

UPC: 198950210232

Origin: imported

The above item details were provided by the Target Plus™ Partner. Target does not represent or warrant that this information is accurate or complete. On occasion, manufacturers may modify their items and update their labels.

We recommend that you do not rely solely on the information presented. If you have a specific question about this item, you may consult the item's label, contact the manufacturer directly or call Target Guest Services at 1-800-591-3869.

If the item details aren’t accurate or complete, we want to know about it.

Shipping & Returns

Shipping details

Estimated ship dimensions: 20.87 inches length x 11.02 inches width x 11.42 inches height

Estimated ship weight: 80.03 pounds
